GCT Diamond Coating Router – Type 1322
Product Details
Routing of inner and outer contours as well as for de-paneling of IMS made of
aluminum and copper
Ideally suited for depth routing of IMS, aluminium and copper, laminate with ceramic fillers.
Very high dimensional accuracy and process capability.
Feed rate increases by factor 3-4, tool life increases up to 12 times.
Description
- Routing of inner and outer contours as well as for de-paneling of IMS made of aluminum and copper
- Ideally suited for depth routing of IMS, aluminum and copper, laminate with ceramic fillers
- Very high dimensional accuracy and process capability
- Feed rate increases by factor 3-4, tool life increases up to 12 times
- No pre-drilling required with Type 1328
specification
- Right hand cutting, right twisted (up cut)
- Fishtail cut – shank Ø 3.175mm
- Overall length 38.10mm
- Tolerances according to GCT router specification
- Made of solid carbide
